Model: Activated carbon filters MS-LFX
Bình chọn của bạn:
Activated carbon filters MS-LFX
1. Mô tả
-
Bộ lọc than hoạt tính MS[]-LFX
-
Size 4, 6, 9, 12
-
Port G1/8, G1/4, G3/8, G1/2, G3/4, G1, G1 1/4, G1 1/2, G2
-
Lưu lượng 250 ... 7090 l/min
-
Áp suất hoạt động 0 ... 20 bar
-
Prefiltration with 0.01 µm grade of filtration recommended.
Danh sách mã Activated carbon filters MS-LFX Hoàng Nguyên cung cấp:
MS4-LFX:
-
Port G1/8, G1/4, G3/8
-
Flow rate max. 360 l/min.
|
Part No |
Order Code |
Port Size | Flow Rate |
Operating pressure |
|
527699 |
MS4-LFX |
|
250 l/min |
0 ... 14 bar |
|
536707 |
MS4-LFX-1/8-R |
G1/8 |
250 l/min |
0 ... 14 bar |
|
536709 |
MS4-LFX-1/8-U |
G1/8 |
250 l/min |
0 ... 14 bar |
|
529467 |
MS4-LFX-1/4-R |
G1/4 |
250 l/min |
0 ... 14 bar |
|
535782 |
MS4-LFX-1/4-U |
G1/4 |
250 l/min |
0 ... 14 bar |
|
529468 |
MS4-LFX-1/4-R-Z |
G1/4 |
250 l/min |
0 ... 14 bar |
|
535783 |
MS4-LFX-1/4-U-Z |
G1/4 |
250 l/min |
0 ... 14 bar |
MS6-LFX:
-
Port G1/4, G3/8, G1/2, G3/4
-
Flow rate max. 900 or 2500 l/min.
|
Part No |
Order Code |
Port Size | Flow Rate |
Operating Pressure |
|
527672 |
MS6-LFX |
|
700 ... 1300 l/min |
0 ... 20 bar |
|
529683 |
MS6-LFX-1/4-R |
G1/4 |
700 l/min |
0 ... 20 bar |
|
529685 |
MS6-LFX-1/4-U |
G1/4 |
700 l/min |
0 ... 20 bar |
|
529687 |
MS6-LFX-3/8-R |
G3/8 |
1000 l/min |
0 ... 20 bar |
|
529689 |
MS6-LFX-3/8-U |
G3/8 |
1000 l/min |
0 ... 20 bar |
|
529679 |
MS6-LFX-1/2-R |
G1/2 |
1200 l/min |
0 ... 20 bar |
|
529681 |
MS6-LFX-1/2-U |
G1/2 |
1200 l/min |
0 ... 20 bar |
|
552927 |
MS6-LFX-1/2-U-HF |
G1/2 |
1300 l/min |
0 ... 20 bar |
|
529684 |
MS6-LFX-1/4-R-Z |
G1/4 |
700 l/min |
0 ... 20 bar |
|
529688 |
MS6-LFX-3/8-R-Z |
G3/8 |
1000 l/min |
0 ... 20 bar |
|
529690 |
MS6-LFX-3/8-U-Z |
G3/8 |
1000 l/min |
0 ... 20 bar |
|
529680 |
MS6-LFX-1/2-R-Z |
G1/2 |
1200 l/min |
0 ... 20 bar |
|
529682 |
MS6-LFX-1/2-U-Z |
G1/2 |
1200 l/min |
0 ... 20 bar |
MS9-LFX:
-
Flow rate max. 6500 l/min.
|
Part No |
Order Code |
Port Size |
Flow Rate |
Operating Pressure |
|
552942 |
MS9-LFX |
|
|
0 ... 20 bar |
|
552996 |
MS9-LFX-3/4-U |
G3/4 |
|
0 ... 20 bar |
|
553032 |
MS9-LFX-1-U |
G1 |
|
0 ... 20 bar |
|
564038 |
MS9-LFX-G-U |
Manifold module |
|
0 ... 20 bar |
MS12-LFX:
-
Port G1, G1 1/4, G1 1/2, G2
-
Flow rate max. 7090 l/min
|
Part No |
Order Code |
Port Size | Flow Rate |
Operating Pressure |
|
535043 |
MS12-LFX |
|
|
0 ... 20 bar |
|
537155 |
MS12-LFX-G-U |
|
4800 ... 6000 l/min |
0 ... 20 bar |
